Technical Parameters
|
Technical dataT |
MST-681T |
|
Fluid pressure ratio |
68:1 |
|
Maximum fluid working pressure |
46.8 MPa/468 bar |
|
Delivery(liter)/MIN |
9 |
|
Displacement per cycle |
180cc |
|
Stroke length (MM) |
120 |
|
Air pressure range(BAR) |
3-7 |
|
Maximum operating temperature |
82ºC (180ºF) |
Product Features
The MST-681T high pressure airless sprayer is suitable for coating operations on large components such as steel structures, ships, automobiles, doors, trailers, bridges, railway vehicles, containers, pipelines, oil tanks, lifting equipment, storage tanks, aerospace, and more. It can efficiently complete the spraying of new coatings and thick-film heavy-duty anti-corrosion coatings with high construction difficulty. Additionally, it is compatible with 830 and 831 marine paints, epoxy resin, silver powder paint, epoxy asphalt, polyurethane topcoat, epoxy mica iron intermediate paint, door-specific fireproof glue, foam glue, high-pressure glue, cold-pressed glue, and other glues, as well as conventional paints, waterproof coatings, fluorocarbon coatings, ceramic coatings, and various other coating materials.
